Pinch Roll
The basic function of pinch rolls is to push the material in a particular direction. It does not cause any kind of physical change in the material and is usually used to move the material over a distance.
- Product Description
- Features / Specification
- Gallery
- Quick Inquiry
Product Description
It is installed at various places in a rolling mill such as between the roughing mill and the intermediate mill, before and after the TMT Quenching Box to maintain the speed and tension of bars. It is driven through AC/DC Motor and consists of 2 Hi Gear Box, solid rolls with cardan shaft.
DC Pinch Rolls are installed at different places in a working rolling mill, including the place between roughing mill and intermediate mill as well as before and after TMT quenching box. The use of these rolls support maintenance of speeds and provide for consistent tension of bars
AC Pinch Rolls find application in pushing material in particular direction and are designed to deliver precision working, thus allowing movement of the material over a distance without making in them any physical changes.
Features / Specification
- DC Pinch Rolls are made available in two versions - conti-leaver type and pneumatic up to 360mm crs
- We hold expertise in providing AC pinch roll comprising conti-leaver type mechanical up to 400mm crs
- Pinch rolls featuring use of sensors that allows precision breaking up of speed of hot flowing material
- Top roll comes raised pneumatically or lowered with bottom roll in adjustable finish
- Pinch roll housing comprising sturdy welded construction
- Pinch rolls feature wear resistant surface with anti friction bearing mounting support
- Pneumatic cylinder for raising /lowering upper rocker arm
- Spindle provided for meeting the needs of adjustment of bottom pinch rolls
